Panpu EC Permanent Magnet Fan Case | Cleanroom Operator | Energy-Saving Retrofit of Cleanroom Fan Clusters with On-Demand Speed Control
The original AC fan bank in the cleanroom of an electronics manufacturing facility operated at a fixed speed, causing significant energy waste due to damper throttling and generating excessive noise that affected the work environment. The project replaced all AC fans with EC permanent magnet motors and implemented closed-loop demand-based airflow control using pressure sensors, managed centrally by an intelligent linkage system for multiple units. Post-retrofit, the cleanroom's air system now operates on demand, achieving significant improvements in both noise levels and energy consumption, with annual electricity savings exceeding projected targets.
RESULTS
Transformation Results
SAVING RATE
Overall energy consumption reduction after retrofit
ENERGY COMPARE
Annual Energy Consumption Comparison (Unit: 10,000 kWh)
KEY METRICS
The fan system operates on demand, simultaneously reducing workshop noise and energy consumption.
Data Scope and Validation Source: The above metrics are derived from on-site measurements under identical operating conditions before and after the retrofit (comparing energy meter readings with equipment operation logs). The statistical period covers 30 consecutive days of full operation post-retrofit. Motor energy efficiency ratings follow GB 18613-2020 and IEC 60034-30-1, while product efficiency values are cited from the manufacturer's factory test reports. Actual results may vary based on load rate, annual operating hours, and specific operating conditions.
